Product features:
Hydrophone of YH-35 is a piezoelectric sensor for prospecting purpose in deep sea,
its working depth is 100 meters, it is small in size, stable, high sense for output and non-directional
receiving, its high temperature injection molding seal makes it better for water proof, its tail suspension
wire’s design makes it more suitable for field wiring.
YH-35 Specifications
|
Description
|
YH-35
|
|
Natural Frequency(Hz)
|
10±10%
|
|
DC Resistance (DCR)(Ω)
|
155±10%
|
|
Voltage Sensitivity(V/Bar)
|
14±1.5 dB
|
|
Operational Depth(m)
|
1.0~100
|
Dimensions:
Length: 158mm (6.22in) with case
Diameter: 60mm (2.36in) with case
Weight: 530g
The working depth ranges from 1.0m to 100m and can be interchanged with MP-25 , P-44A and LS-2512 etc.
*the picture is only for reference,subject to real object.*
|
